SKU: 393250
Arrone Touchbar Rebated Double Door Panic Bar Set - Timber Door - Silver
0.0
(0)
4 in stock
For public areas
£210.59each+ VAT
VAT
Large Item
This item carries a £4.95 large item surcharge - x1 surcharge per order!
Free returns within 28 days
Frequently bought together
Current item
Main Product
£210.59
Each + VAT
View bulk savings
1-9
£210.59
10+
£210.59
20+
£210.59
Added
Details
Product code: 393250
£210.59
Each + VAT
View bulk savings
1-9
£210.59
10+
£210.59
20+
£210.59
About this product
- For public areas
- Set comprises of Arrone panic bolt and Arrone panic latch and Arrone 2 point panic bolt
- Each door leaf up to 1000mm wide
- Doors up to 2200mm high
- Suitable for double rebated doors
- Non handed
- Vertical Pullman latches with stainless steel latchbolts
- BS EN 1125: A panic application where the exit door is used by the public and provides ""safe and effective escape through the doorway with minimum effort and without prior knowledge of operation"".
- For example: theatres, shops, schools, hospitals and cinemas
- For non-public areas such as offices, select products that are BS EN 179 applicable
Specification & Documentation
Application
Timber
CE Rated
Yes
Certifire
Yes
Environment
Public
Finish
Silver
Locking Points
3
Max Door Height (mm)
2200
Max Door Width (mm)
1000
To Suit
Double Door
Type
Rebated Bar Set
Material
304 Stainless Steel
Pack Quantity
1
Update
Details
Previous Product
Next Product
About this product
- For public areas
- Set comprises of Arrone panic bolt and Arrone panic latch and Arrone 2 point panic bolt
- Each door leaf up to 1000mm wide
- Doors up to 2200mm high
- Suitable for double rebated doors
- Non handed
- Vertical Pullman latches with stainless steel latchbolts
- BS EN 1125: A panic application where the exit door is used by the public and provides ""safe and effective escape through the doorway with minimum effort and without prior knowledge of operation"".
- For example: theatres, shops, schools, hospitals and cinemas
- For non-public areas such as offices, select products that are BS EN 179 applicable
Specification & Documentation
Application
Timber
CE Rated
Yes
Certifire
Yes
Environment
Public
Finish
Silver
Locking Points
3
Max Door Height (mm)
2200
Max Door Width (mm)
1000
To Suit
Double Door
Type
Rebated Bar Set
Material
304 Stainless Steel
Pack Quantity
1
